Jetway HBJC924R3288DG2NS (ARM Cortex A17)

Jetway HBJC924R3288DG2NS (ARM Cortex A17)

  • Rockchip® ARM Cortex A17 RK3288 Quad-core 1.8GHz
  • Onboard 1333 /2GB DDR3L DRAM
  • Onboard 8G Flash ROM up to 64GB
  • 1* Realtek® Gigabit LAN, 1* 802.11b/g/n 2.4G WIFI and BT-V4.0
  • Support 1* Micro SD Socket (Max. 64G)
  • 4* USB2.0 , 1* OTG, 26bit GPIO, 1* HDMI, 1* Audio Port
  • 5V DC-in


Share

229.00 EUR
incl. 19% VAT, plus shipping
Available in 3 weeks.
Will be ordered for you.
Add to cart
MB Model – JR3288A-DG2N (1.8” SBC)
Part No – HBJC924R3288DG2NS
CPU/Chipset – Rockchip® ARM Cortex A17 RK3288 1.8GHz Quad core
– Rockchip® RK808-B
Memory – 2GB/1333MHz DDR3L
Storage – 8GB Flash (Max 64GB)
Network – 1 * REALTEK RTL8211E‐VB Gigabit LAN
– 1 * REALTEK RTL8723BS 802.11b/g/n 2.4G WIFI and BT-V4.0
Rear Panel I/O – 1 * RJ45
– 4 * USB2.0
– 1 * Micro SD Socket (Front)
Side Panel I/O – 1 * OTG / DC Jack
– 1 * HDMI (Max Resolution: 1920×1080@60Hz)
– 1 * Audio
Internal Connector – 26bit GPIO, 1* I2C
– 1* MIPI DSI
– 1* MIPI CSI
Power Source – DC 5V-3.0A
– AC 100~240V input
Compliance – RoHS, ErP Ready
Temperature – Operating Temperature: -10 ~ 60° C
– Storage Temperature: -20 ~ 65° C
Dimensions – 87.0(W) x 56.0(D) x 2.9(H) mm
– Shelf: 110.0(W) x 111.1(D) x 33.6(H) mm
OS Support – Android 5.1, Linux Debian 9.0
Warranty – 1 Year limited warranty
Data sheet Download (PDF)
Data sheet Print view
